Engine
Electric start – sealed battery included
Frame
Reinforced powder coated steel frame · 13-inch flat-free tires
Components
Easy-access and protected control panel with magnetic circuit breakers and GFCI-protected receptacles · Large low tone muffler · Easy-to-read fuel gauge · Idle control · Voltmeter/hour meter · Heavy-duty industrial air cleaner · USDA/USFS-approved spark arrestors
MSRP: $9,600.00
Noise level tested at seven meters (75% load). Rating represents minimum noise level rating.
| Max AC Output | 14000 watts |
| Rated AC Output | 12000 watts |
| Displacement/Engine | 670cc Mi-T-M OHV with electric start - sealed battery include |
| Alternator | Brushless 120V/240V, 60Hz |
| Maximum Amps (120V/240V) | 116.7/758.3 |
| Continuous Amps (120V/240V) | 100.0/50.0 |
| Receptacles | (2) 120V, 20A GFCI duplex, (1) 120V, 30 A twist lock, (1) 120V/240V, 30A twist lock, (1) 120V/240V, 50A |
| Circuit Breakers | (2) 20A toggle circuit breakers, single pole, (1) 30A toggle circuit breaker, single pole, (1) 30A toggle circuit breaker, double pole, (1) 50A toggle circuit breaker, double pole |
| Fuel Capacity | |
| Rated Speed | 3600 RPM |
| Decibel Rating | 80.0 |
| Run Time (at full load) | 8.0 hours |
| Idle Control | Yes |
| Net Weight | 493.00 lbs. |
| Shipping Weight | 553.00 lbs. |
| Length | 31.50 in. |
| Width | 30.50 in. |
| Height | 37.50 in. |
Skid Feet GX-0003
For stationary applications
50-Amp Twist Lock Receptacle GX-0005
Marine receptacle for routine marine applications
