Perfect for cleaning heavily soiled equipment located inside commercial facilities. Use this unit to clean grimy floors and concrete walls or garages and service shops. It's a great tool to keep indoor pools free from dirt, mold and mildew.
Pump: Belt drive triplex piston General pump with ceramic plungers · Stainless-steel and brass unloader with preset pressure · Forged brass manifold · Thermal relief valve · Water filter with clear sleeve for screen inspection · External bypass system allows more water into the system to protect from heat build-up
Motor: Totally enclosed fan-cooled electric motor with thermal overload protection · 10-foot power cord
Frame: Powder coated steel frame and base plate with tube handles · 13-inch flat-free tires · Enclosed belt guard
Component: Heavy-duty dual cogged belt drive system
Unit Includes: Quick connect nozzles - 0º, 15º, 25º and 40º · 50-foot x 3/8-inch non-marking hose with quick connects, swivel and bend restrictors · Insulated trigger gun with safety lock-off · 36-inch lance with rubber grip
MSRP: $6,364.00
*460V motors available as options
| PSI | 3000 |
| GPM | 4.8 |
| Horsepower/Motor | 10.0 HP, 230V, 3Ø, 26.0A or 10.0 HP, 460V, 3Ø, 13.0A |
| Pump | General |
| Unloader | Factory preset |
| Plug Type | NEMA 15-50P |
| Lance | 36in. |
| Drive Type | Belt Drive Pressure Washers |
| Mobility | Portable Pressure Washers |
| Water Temperature | Cold Water Pressure Washers |
| Net Weight | 376.00 lbs. |
| Shipping Weight | 450.00 lbs. |
| Length | 45.50 in. |
| Width | 32.50 in. |
| Height | 30.00 in. |
Insulated Dual Lance CX-0005
Has both a high and low pressure top that allows you to switch to the low pressure chemical injector without having to change tips - 36-inch
460V on 10.0 HP, 3 Phase Models CX-0062
For when you have 460V of power available
Stationary Option CX-0094
This option will remove the existing tall handle and wheels, which will be replaced with a short handle and rubber feet for stationary applications
